HLM G-414 Extra Heavy Wire Rope Thimbles, Hot Dip galvanized | Rope Size:6-56mm | Weight:7-2780lb
$0.01HLM INDUSTRY G-414 Extra Heavy Wire Rope Thimbles
Available in Hot Dip galvanized or Stainless Steel (Type 304).
Stainless steel recommended for more corrosive environments where greater protection is required.
Greater protection against wear and deformation of the wire rope eye.
Longer service life.
HLM G-414SL Extra Heavy Wire Rope Thimbles(Shackle-Loc), Hot Dip Galvanized | Rope Size:9-38mm | Weight: 24-1317lb
$0.01HLM INDUSTRY G-414SL Extra Heavy Wire Rope Thimbles(Shackle-Loc)
Prevents the shackle from being removed and replaced in the field, which could compromise the certified integrity of the sling assembl.
Available in Hot Dip galvanized. HLM’s shackle locking thimbles are galvanized after the welding of the wedge has been completed.
Greater protection against wear and deformation of the wire rope eye.
Longer service life.
HLM G-429 Fist Grip , Galvanized | Rope Size:5-40mm | Weight:23-700lb
$0.01HLM INDUSTRY G-429 Fist Grip
Entire clip is Galvanized to resist corrosive and rusting action.
Based on the catalog breaking strength of wire rope, HLM wire rope clips have an efficiency rating of 80% for 3/16″ through 7/8″ sizes, and 90% for sizes 1” through 1-1/2
Bolts are an integral part of the saddle. Nuts can be installed in such a way as to enable the operator to swing the wrench in a full arc for fast installation.
All sizes have forged steel saddles.
All Clips are individually bagged or tagged with proper application instructions and warning information.
Meets or exceeds all requirements of ASME B30.26 including identification, ductilit,design factor, proof load and temperature requirements. lmportantly, these wire rope clips meet other critical performance requirements including fatique life, impact proper-ties and material traceability, not addressed by ASME B30.26.
Assembled with standard heavy hex nuts.
HLM G-450 Wire Rope Clip, Galvanized | Rope Size:1/8–**3-1/2in | Weight: 6-4000lb
$0.01HLM INDUSTRY G-450 Wire Rope Clip
Each base has a Product ldentification Code (PlC) for material traceabilit , the name HLM or CG, and a size forged into it.
Based on the catalog breaking strength of wire rope, HLM wire rope clips have an eficiency rating of 80% for 1/8″ through 7/8″ sizes, and 90% for sizes 1″ through 3-1/2″.
Entire Clip is Galvanized to resist corrosive and rusting action.
Sizes 1/8″ through 2-1/2″ and 3″ have forged bases.
All Clips are individually bagged or tagged with proper application instructions and warning information.
Clip sizes up through 1-1/2″ have rolled threads.
Meets or exceeds all requirements ofASME B30.26 including identification, ductilit , design factor, proof load and temperature requirements. lmportantly, these wire rope clips meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
Look for the Red-U-Bolt®, your assurance of Genuine HLM Clips.
HLM HG-223 Hook and Hook Turnbuckle, Hot Dip galvanized steel | WLL: 400-5,000lb | Body Has UNC Threads
$0.01HLM INDUSTRY HG-223 Hook and Hook Turnbuckle
- End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing.
- Hot Dip galvanized steel.
- Hooks are forged with a greater cross sectional area that results in a stronger hook with better fatigue properties.
- TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
- Modified UNJ thread on end fittings for improved fatigue properties
- Body has UNC threads.
- Fatigue Rated.
- Meets or exceeds all requirements of ASME B30.26 including identificatio , ductility, design factor, proof load and temperature reauirements. lmportantly, these turnbuckles meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
- Meets the performance requirements of Federal Specifications FF-T-791b, Type 1 Form 1 — CLASS 5, and ASTM F-1145, except for those provisions required of the contractor.
- Proof Load is 2.5 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit.
HLM HG-225 Hook and Eye Turnbuckle, Hot Dip galvanized steel | WLL: 400-5,000lb | Weight: .31-13.9lb
$0.01HLM INDUSTRY HG-225 Hook and Eye Turnbuckle
- End fitings are Quenched and Tempered or Normalized, bodies heat treated by normalizing.
- Hot Dip galvanized steel.
- Turnbuckle eyes are forged elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckles sizes 1/4″ through 1″, a shackle one size smaller can be reeved through eye.
- Turnbuckle hooks are forged with a greater cross sectional area that results in a stronger hook with better fatigue properties.
- TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
- Modified UNJ thread on end fittings for improved fatigue propertie
- Body has UNC threads.
- Fatique Rated.
- Meets or exceeds all requirements of ASME B30.26 including identification, ductilit , design factor, proof load and temperature requirements. lmportantly, these turnbuckles meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
- Meets the performance requirements of Federal Specifications FF-T-791b, Type 1 Form 1 — CLASS 6, and ASTM F-1145, except for those provisions required of the contractor.
- Proof Load is 2.5 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit.
HLM HG-226 Eye and Eye Turnbuckle, Hot Dip galvanized steel | UNJ Thread for Enhanced Fatigue Resistance | WLL: 500-75,000lb
$0.01HLM INDUSTRY HG-226 Eye and Eye Turnbuckle
- End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing
- Hot Dip galvanized steel.
- Turnbuckle eyes are forged elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckle sizes 1/4″ through 2-1/2″, a shackle one size smaller can be reeved through eye.
- Modified UNJ thread on end fittings for improved fatigue properties. Body has UNC thread
- TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
- Fatique Rated.
- Meets or exceeds all reguirements of ASME B30.26 including identification, ductilit , design factor, proof load and temperature reguirements. lmportantly, these turnbuckles meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26
- Meets the performance requirements of Federal Specifications FF-T-791b, Type 1 Form 1 — CLASS 4, and ASTM F-1145, except for those provisions required of the contractor.
- Proof Load is 2.5 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit.
HLM HG-227 Jaw and Eye Turnbuckle, Forged Elongated Eyes for Easy Attachment & Reduced Stress | Hot Dip galvanized steel | Weight: .33-187lb
$0.01HLM INDUSTRY HG-227 Jaw and Eye Turnbuckle
- End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing.
- Hot Dip galvanized steel.
- Turnbuckles eyes are forged and elongated, by design, to maximize easy attachment in system and minimize stress in the eye. For turnbuckles size 1/4″ through 2-1/2″, a shackle one size smaller can be reeved through eye.
- Forged jaw ends are fitted with bolts and nuts for 1/4″ through 5/8″, and pins and cotters on 3/4” through 2-3/4″sizes.
- Modified UNJ thread on end fittings for improved fatigue properties
- Body has UNC threads.
- TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
- Fatique Rated.
- Meets or exceeds all requirements of ASME B30.26 including identification, ductilit , design factor,proof load and temperature requirements. lmportantly, these turnbuckles meet other critical performance reguirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
- Meets the performance requirements of Federal Specifications FF-T-791b, Type 1 Form 1 — CLASS 8, and ASTM F-1145, except for those provisions required of the contractor.
- Proof Load is 2.5 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit.
HLM HG-228 Jaw and Jaw Turnbuckle, Hot Dip galvanized steel | Proof Load: 2.5×WLL | Ultimate Load: 5×WLL
$0.01HLM INDUSTRY HG-228 Jaw and Jaw Turnbuckle
- End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing.
- Hot Dip galvanized steel.
- TURNBUCKLES RECOMMENDED FOR STRAIGHT OR IN-LINE PULL ONLY.
- Forged jaw ends are fitted with bolts and nuts for 1/4″ through 5/8″, and pins and cotters on 3/4″ through 2-3/4”sizes.
- Modified UNJ thread on end fittings for improved fatigue propertieBody has UNC threads.
- Fatigue Rated.
- Meets or exceeds all requirements of ASME B30.26 including identification, ductilit , design factor, proof load and temperature reguirements. lmportantly, these turnbuckles meet other critical performance reguirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
HLM HS-251 Stub End Turnbuckles, Drop Forged Steel | Complete assembly is self-colored | WLL: 1,200-21,400lb
$0.01HLM INDUSTRY HS-251 Stub End Turnbuckles
- End fittings are Quenched and Tempered or Normalized, bodies heat treated by normalizing.
- Complete assembly is self-colored.
- Reference American Welding Society Specifications for proper welding procedures
- Meets the performance requirements of Federal Specifications FF- T-791b, Type 1 Form 1 – CLASS 3, and ASTM F-1145, except for those provisions required of the contractor.
HLM Italian Type Wire Rope Clip, Size: 2-22 | AISI304/316L | Architectural & Yacht Rigging Systems
$0.01HLM INDUSTRY Italian Type Wire Rope Clip
AISI 304/316 Stainless Steel – Exceptional resistance to saltwater, humidity and harsh weather
Italian-Style Design – Taller, sleeker profile for improved aesthetics and performance
Secure Fastening – Includes two threaded bolts with hex nuts for a vibration-resistant grip
Reusable & Easy to Install – Compatible with standard wrenches for quick setup
Wide Size Range – Available for 2mm to 22mm wire ropes
HLM JIS Type Wire Rope Clip, Securing Wire Ropes | Size: 2-22 | AISI304/316L
$0.01HLM INDUSTRY JIS Type Wire Rope Clip
Premium Stainless Steel – Resists rust, corrosion, and wear
Secure Grip – U-bolt and saddle design ensures a tight, vibration-resistant hold
Smooth Surface – Polished finish minimizes rope damage
Easy Installation – Simple setup with standard tools
Versatile Use – Ideal for marine, construction, and industrial applications
