HLM Type L Coil Inserts, Bolt Diameter: 1/2″-3/4″ | SWL Tension: 2,250-3,550 lbs | Angled-Leg Anchor for Edge Stability

HLM INDUSTRY Type L Coil Inserts

Type L Coil Insert maximizes edge-load capacity by leveraging angled embedment and lateral concrete engagement to optimize shear resistance, with optional side-mount configurations for formwork-integrated installation.​

  •  Bolt Diameter: 1/2″-3/4″
  • SWL Tension: 2,250-3,550 lbs
  • Application Purpose:​​ Designed specifically for lifting and handling lightweight precast concrete elements.
  • Layout Requirement:​​ Minimum spacing between inserts is twice the corner distance.
Inquiry Now
Category:

Type L Coil Insert, Angled-Leg Anchoring with Lateral Load Transfer for Enhanced Edge-Lift Stability in Thin Concrete Sections.​

HLM INDUSTRY – China Manufacturer, Supplier and Factory

Type L Coil Insert | Reinforces Concrete Edge Stability through Angled Embedment and Lateral Load Distribution.​

Welcome​ to buy the ​newest and cheapest​ Type L Coil Inserts from ​HLM INDUSTRY. We are one of the leading manufacturers and suppliers in China, offering wholesale, OEM services, and discounted pricing. With ​CE certification, our in-stock products are manufactured to the highest standards in China, ensuring premium quality at competitive prices. Feel free to request a ​free sample.
