HLM Lift Erection Anchor with Shear Plate, Thickness: 3-1/2″ to 12″ | Size: 2T×8″ to 8T×13-1/4″ | Integrated Shear Reinforcement for Edge-Tilt Precast Positioning
HLM INDUSTRY Lift Erection Anchor with Shear Plate
Engineered for High-Stress Edge Lifting with Integrated Shear Plate Reinforcement and Concrete-Sparing Force Distribution.
- Finish:Plain or Hot-Dipped Galvanized.
- Thickness: 3-1/2″ to 12″
- Size: 2T×8″ to 8T×13-1/4″
- Design Purpose:Specifically engineered for horizontal-to-vertical edge lifting and handling of thin-walled precast concrete elements.
- Spall Prevention Feature:Two steel protrusions (“ears”) on the anchor head prevent concrete spalling during operation.
- Mechanical Function:The protrusions restrict ring clutch rotation during lateral pulls, transferring forces directly to the anchor edge instead of the concrete.
- Structural Optimization:The anchor body is shaped to accommodate full reinforcement, ensuring secure support and spall-free rotation.
HLM INDUSTRY – China Manufacturer, Supplier and Factory
Lift Erection Anchor with Shear Plate | Engineered for High-Stress Edge Lifting with Integrated Shear Reinforcement and Spall-Resistant Load Transfer.
Welcome to buy the newest and cheapest Lift Erection Anchor with Shear Plate from HLM INDUSTRY. We are one of the leading manufacturers and suppliers in China, offering wholesale, OEM services, and discounted pricing. With CE certification, our in-stock products are manufactured to the highest standards in China, ensuring premium quality at competitive prices. Feel free to request a free sample.
