HLM L-320AN EYE HOOK , Alloy Steel Eye Hoist Hook with Latch |5:1 Design Factor for 1t – 22t

HLM INDUSTRY L-320AN EYE HOOK

All HLM L-320 Eye Hoist Hooks incorporate the following features:

• The most complete line of Eye hoist hooks.
• Available in carbon steel and alloy steel.
• Designed with a 5:1 Design Factor for (Carbon Steel); 4.5:1 Design Factor for 30t – 60t (Alloy Steel).
• Eye hooks are load rated.
• Proper design, careful forging and precision controlled quenched and tempering give maximum strength without excessive weight and bulk.
• Every HLM Eye Hook is equipped with a latch. Even years after purchase of the original hook, latch assemblies can be added.
• Chemical analysis and tensile tests performed on each PlC to verify chemistry and mechanical properties.
• Type Approval certification in accordance with ABS 2016 Steel Vessel and Guide for Certification of Lifting Appliances 2016 available.Certificates available when requested at time of order and may include additionalcharges.
• Meets ASME B30.10
• Hoist hooks incorporate two types of strategically placed markings forged into the product which address two (2)QUIC-CHECK® features:
• Deformation Indicators and Angle Indicators

The following additional features have been incorporated in the new HLM L-320N Eye Hoist Hooks(Sizes 3/4 metric ton Carbon through 22 metric ton Alloy.)

• Metric Rated at 5:1 Design Factor for (Carbon Steel); 5:1 Design Factor for 1t – 22t (Alloy Steel).
• Can be proof tested to 2 times the Working Load Limit.
• Low profile hook tip
• New integrated latch (S-4320) meets the world-class standard for lifting.
•  Heavy duty stamped latch interlocks with the hook tip.
• High ciycle, long life spring.
• When secured with proper cotter pin through the hole in the tip of hook, meets the intent of OSHARule 1926.1431(g) and 1926.1501(g) for personnel hoisting.

Hoist hooks incorporate markings forged into the product which address two (2) QUIC-CHECKe features.

• Deformation Indicators — Two strategically placed marks, one just below the shank or eye and the other on the hook tip, which allows for a QUlC-CHECKe measurement to determine if the throat opening has changed, thus indicating abuse or overload. To check, use a measuring device (i.e, tape measure) to measure the distance between the marks. The marks should align to either an inch or halfinch increment on the measuring device.If the measurement does not meet this criteria, the hook should be inspected further for possible damage.
• Angle lndicators — lindicates the maximum included angle which is allowed between two (2) sling legs in the hook.These indicators also provide the opportunity to approximate other included angles between two sling legs.
